Description
Key Specifications
Engine power: 24.5 hp
Lift capacity at 610 mm (24 in.) behind lift point: 318 kg
Max PTO Power: 18.5 hp
Transmission: HST, 2 range
Max speed forward: 16.5 km/h
Engine
Engine type: 3 cylinder, water cooled, 4 cycle, Indirect Injection (IDI)
Fuel: Diesel
Displacement: 1.00 L
Max Torque: 57.00 Nm
Gross Power (ECE-R120): 24.50 HP
Net Power: 23.00 HP
Rated revolution: 3200.00 RPM
Alternator: 12V 50A
Air Cleaner: Dry type, replaceable
Fuel tank: 25.50 L
Drive Train
Transmission: HST, 2 range
Shuttle Type: Hydrostatic Drive
Max. Travelling Speed Forward: 16.50 km/h
Max. Travelling Speed Reverse: 11.20 km/h
Steering: Hydrostatic Power Steering
Turning radius(w/brake): 2540.00 mm
Brake type: Wet disc type
Mechanical differential lock: Rear Std.
Hydraulic System
Implement Pump: 18.70 L/min
Power steering pump: 7.00 L/min
Total hydraulic flow: 25.70 L/min
No.of Std. remote valve’s ports (Rear): Std. (2 port)
PTO
Max PTO Power: 18.50 HP
Rear PTO type: Independent
Rear PTO speed: 540.00 RPM
Mid PTO speed: 2200.00 RPM
Tires
Turf tires: Front: 18×8.5-10 R3 / Rear: 26×12.00-12 R3
Industrial Tires: Front: 18×8.5-10 R4 / Rear: 26×12.00-12 R4
Dimensions
Overall Length with Ballast Weights: 2834.00 mm
Overall Length: 2523.00mm
Overall Width: 1160.00 mm
Overall height (folded ROPS): 1616.00 mm
Overall height: 2224.00 mm
Wheelbase: 1400.00 mm
Front track width: 930.00 mm
Rear track width: 864.00 mm
Ground Clearance under the Rear Axle (Hitch Frame): 160.00 mm
Turning radius: 2540.00 mm
Standard Features
4 Wheel Drive: yes
Rear View Mirror: yes
Battery: yes
Horn: yes
7 Pin Socket: yes
OPC: yes
Cup holder: yes
SMV sign: yes
PTO Cover: yes
HST Cruise: yes
Toolbox: yes
Front Hitch: yes
Hydrostatic Power Steering: yes
Rear folding ROPS: yes
Rear PTO, Independent: yes
12V Aux: yes
Beacon Ready Wiring: yes
Engine Hood, one piece: yes
